Motic B1-253 Trinocular Microscope

The Motic B1-253 Biological trinocular Microscope includes the following:

• Objective Lenses: Ball bearing quadruple nosepiece holds your choice of Semi-Plan Achromat or super high contrast 4x, 10x, 40xs and 100xs Oil objectives.
• Eyepieces: Widefield 10x eyepieces, FN18. 30° inclined binocular tubes. (WF15x and WF20x eyepieces are also available). Trinocular head rotates 360° and light is split 50/50 to camera port and eyepieces. Interpupillary distance adjustment from 55-75mm. Eyepiece accepts 19mm diameter reticle.
• Total Magnification: 40x, 100x, 400x, 1000x
• Specimen Stage: Large 140mm x 135mm rectangular mechanical stage. Includes built in low position coaxial controls with 78mm (x) movement and 50mm (y) movement. Vertical travel range is 27mm.
• Stand: Rugged cast aluminum, gray enamel finish.
• Focusing: Coaxial coarse and fine focusing controls, coarse has tension adjustment, fine is graduated.
• Condenser: 1.25 N.A. Abbe condenser has rack & pinion focusing, iris diaphragm, swing-out filter holder.
• Illumination: Built in illumination, 3w LED with intensity control. 110V power supply, UL approved.
• Size: 15" high, 16 lbs.
• Warranty: Five year warranty excluding electrical parts.

 Motic part #s: B1-253ASC, B1-253SP, 1100100501131, 1100100501121

NOTE: This item is not returnable.
