Reticle Grid 0.5mm Squares 400 Total Labeled
Reticle Grid 0.5mm Squares 400 Total Labeled
Reticle Grid 0.5mm Squares 400 Total Labeled

Reticle Grid 0.5mm Squares 400 Total Labeled

No reviews yet Write a Review
KR-432 glass eyepiece reticle. Grid 10mm x 10mm. 400 squares total (20x20) labeled with numbers horizontal (1-10) and letters vertical (A-J). Diagonal = 14.14mm… Read more
SKU: KR432
Measurement: Metric
Square Size: 0.5mm
$125.00
icon Share icon Share
Request a quote
Description

KR-432 glass eyepiece reticle. Grid 10mm x 10mm. 400 squares total (20x20) labeled with numbers horizontal (1-10) and letters vertical (A-J). Diagonal = 14.14mm. Available in a variety of diameters; select when ordering.

  • Each Square: 0.5mm when using 1x objective
  • Lines: Chrome deposition
  • Chamfer: 0.010" - 0.020"
  • Flatness: 2 waves or better
  • Centering: Within 0.005"
  • Glass Thickness: 1.5mm+/-0.2mm
  • Surface Quality: 20/10
  • Parallelism: 2 min.

NOTE: This is a special order product. Please allow 2-3 weeks for delivery. This item is not returnable.
